Experience professional-grade visuals with our 4K PTZ camera, featuring 4K@30fps crystal-clear resolution and a 1/2.5" Sony CMOS sensor. Capture every detail in stunning clarity, from vibrant colors to low-light scenes, with fluid motion and minimal noise. Perfect for video conferences, remote education, and live streaming.

Monocular technology automatically follows speakers, keeping them centered in the frame without manual adjustment. Perfect for dynamic meetings with multiple

Advanced Optical & Imaging Features
10/12/20X optical zoom (2.9°–58° horizontal FOV) + 16X digital zoom for versatile framing.
Ultra-low illumination capability (0.1Lux color, 0.01Lux B&W) with 2D/3D DNR for clear footage in dim environments.

Multi-Format Video Outputs
Supports 4K@30fps via HDMI, USB3.0, and network; 1080P60 via 3G SDI for flexible connectivity.
Compatible with diverse HD formats (e.g., 1080P, 720P) for seamless integration with different systems.

Compatible with Zoom, Teams, Webex...

3 Mounting Options: Desktop, ceiling, or wall-mounted to fit any conference room setup which makes this model suitable for various projects and events such as video conferencing, LIve-streaming, education,church, tele-medicing...

| Camera | ||
| Model No. | WS-PTZ40WL | |
| Optical Zoom | 10/12/20X | |
| Signal system | 3840×2160P30/25, 1080P60/50/30/25, 1080I60/50, 720P60/50 | |
| Sensor | 1/2.5 inch HQ CMOS sensor, 8.51 magepixels | |
| Scanning mode | progressive | |
| Digital zoom | 16X | |
| Minimum illumination | Support ultra-low illumination:[email protected](color), [email protected](b&w) | |
| Shutter speed | 1/30s ~ 1/10000s | |
| White balance | Indoor/Outdoor/Auto/Manual | |
| BLC | Yes | |
| DNR | 2D&3D DNR | |
| SNR | ≥52dB | |
| Horizontal Fov | 2.9°(Tele)–58°(Wide) | |
| Pan rotation | ±170º | |
| Tilt rotation | -30° ~ +90° | |
| Pan control Speed | 1 º/s ~ 100 º/s | |
| Tilt control Speed | 1 º/s ~ 60 º/s | |
| AI Tracking | AI Monocular Humanoid Tracking | |
| Image flip | Support | |
| Preset number | 255 | |
| Accuracy of preset | ±0.1° | |
| Input/Output Interface | ||
| HD video interface | HDMI | Max 4KP30 |
| USB3.0 | Max 4KP30, UVC1.1, PTZ | |
| SDI | Max 1080P60(BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard) | |
| LAN | Network protocol: IPv4, TCP, UDP, HTTP, NTP, DNS, DHCP, ARP, RTSP, RTP, RTCP, ONVIF, RTMP,RTMPS,VISCA OVER IP, NDI|HX(optional). | |
| Communication interface | 1 *, RS-232 IN, Longest distance: 30 m, VISCA/Pelco-D/Pelco-P protocol | |
| 1 *, RS-422 , Longest distance: 1200 m, VISCA/Pelco-D/Pelco-P protocol | ||
| Power interface | JEITA Type(DC IN 12V)HEC3800 | |
| PoE:802.3af(Optional) | ||
| General Specifications | ||
| Input voltage | AC110V-AC220V to DC12V(DC11.5-DC12.5V) | |
| Input current | DC12V/3A | |
| Working temperature | 0℃~+45℃ | |
| Storage temperature | -10℃~+60℃ | |
| Power consumption | 15W(MAX) | |
| Package size | (Length)173 × (Width)150 x (Height)186mm | |
| Weight | 2.1KG(NET:1.0KG) | |
Notice:Specifications and information of the camera are for reference only, and the contents are subject to change without prior notice.
