Adopting 1/2.8 inch, 2.07 magepixel SONY CMOS Sensor, ,it can achieve high-quality images with a maximum resolution of 1920x1080

The camera's auto-tracking function can automatically select the face closest to the camera for tracking. The tracking speed can be adjusted in the menu.

Simultaneous NDI/LAN, USB3.0, HDMI 2.0 and 3G-SDI. four channels video output. HDMI: 1080P60/50/30/25, 720P60/50 etc. USB3.0: 1080P60/50/30/25, 720P60/50 etc. LAN:1080P60/50/30/25, 720P60/50 etc. 3G-SDI:1080P60/50/30/25, 720P60/50 etc.

This camera offers 10X, 12X, and 30X optical zoom options with different FOVs respectively. Its advanced focusing algorithm ensures rapid and accurate focus even during zoom or movement.

Compatible with Zoom, Teams, Webex...

3 Mounting Options: Desktop, ceiling, or wall-mounted to fit any conference room setup which makes this model suitable for various projects and events such as video conferencing, LIve-streaming, education,church, tele-medicing...

| Camera | ||
| Model No. | WS-PTZ20 | |
| Optical Zoom | 10/12/20X | |
| Signal system | 1080P60/50/30/25, 720P60/50 | |
| Sensor | 1/2.8 inch HQ CMOS sensor, 8.51 magepixels | |
| Scanning mode | progressive | |
| Digital zoom | 12x | |
| Minimum illumination | Support ultra-low illumination:[email protected](color), [email protected](b&w) | |
| Shutter speed | 1/30s ~ 1/10000s | |
| White balance | Indoor/Outdoor/Auto/Manual | |
| BLC | Yes | |
| DNR | 2D&3D DNR | |
| SNR | ≥52dB | |
| Fov | 10X lens: f=4.7~94mm FoV: 55°(W)~5.5°(T) | |
| 12X lens: f=4.3~51.6mm FoV: 70.5°(W)~5.2°(T) | ||
| 20X lens: f=4.7~94mm FoV: 55.4°(W)~2.9°(T) | ||
| Pan rotation | ±170º | |
| Tilt rotation | -30° ~ +90° | |
| Pan control Speed | 1 º/s ~ 100 º/s | |
| Tilt control Speed | 1 º/s ~ 60 º/s | |
| AI Tracking | AI Monocular Humanoid Tracking supported | |
| Image flip | Support | |
| Preset number | 255 | |
| Accuracy of preset | ±0.1° | |
| Input/Output Interface | ||
| HD video interface | HDMI | Max 1080P60 |
| USB3.0 | Max 1080P60, UVC1.1, PTZ | |
| SDI | Max 1080P60(BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard) | |
| LAN | Network protocol: IPv4, TCP, UDP, HTTP, NTP, DNS, DHCP, ARP, RTSP, RTP, RTCP, ONVIF, RTMP,RTMPS,VISCA OVER IP, NDI|HX. | |
| Communication interface | 1 *, RS-232 IN, Longest distance: 30 m, VISCA/Pelco-D/Pelco-P protocol | |
| 1 *, RS-422 , Longest distance: 1200 m, VISCA/Pelco-D/Pelco-P protocol | ||
| Power interface | JEITA Type(DC IN 12V)HEC3800 | |
| PoE:802.3af | ||
| General Specifications | ||
| Input voltage | AC110V-AC220V to DC12V(DC11.5-DC12.5V) | |
| Input current | DC12V/3A | |
| Working temperature | 0℃~+45℃ | |
| Storage temperature | -10℃~+60℃ | |
| Power consumption | 15W(MAX) | |
| Package size | (Length)173 × (Width)150 x (Height)186mm | |
| Weight | 2.1KG(NET:1.0KG) | |
